Functions
 Non-contact temperature measurement: face temperature
measurement with accurately personnel matching.
Temperature accuracy:±0.5 ℃ , detection distance: 0.3
to 3 m, target height: 1.45 m to 1.85 m
 Temperature filtering: adjustable temperature threshold. An
over-threshold temperature will trigger the audible strobe
light
 Counting display: displays the walk-through people number,
metal alarm times, real time temperature, number of
people in abnormal temperature
 Metal detection: metal likes a clip
 Multi-Area alarm: Indicates the metal position on the body.
Max. 18 areas
 Modularized component: easy transmission and installation

Thermal Module

• Image SensorVanadium Oxide Uncooled Focal Plane Arrays
• Max. Resolution160 × 120 (the resolution of output image is 320 × 240)
• Pixel Interval17 μm
• Response Waveband8 μm to 14 μm
• NETDLess than 40 mK (25°C), F# = 1.1
• Lens (Focal Length)3.1 mm
• IFOV5.48 mrad
• Field of View50° × 37.2° (H × V)
• Min. Focusing Distance0.2 m
• ApertureF1.1
